Top Hammer Drilling T45 76mm 89mm 102mm Button Bit For Bench Drilling
Product Specification: T45 Button Bits
Thread Button bit is well known for its high wear resistance on medium-hard to hard abrasive rock formations (between 200 Mpa to 260 Mpa compressive strength). Featuring spherical tungsten carbide inserts that is known to have strong configuration against carbide fracture.
| Product Name: | Thread button bits |
| Description: | For different rock hardness mining,tunneling,quarrying projects. |
| Material: | Alloy steel bar and tungsten carbide bit |
| MOQ: | trial order 1-5pcs |
| Body Type | Normal type and retract type |
| Thread type | R25,R28,R32,R38,T38,T45,T51,ST58,ST68 |
| Diameter | 32mm-152mm |
| Button bit shape | Spherical and Ballistic |
| Face shape | Flat shape and Drop-center shape |
T45 button bits
| Bit Dia. | Buttons and Size (mm) | Flushing Hole | Weight |
| mm | inch | Front | Gauge | Angle | Front | Side | kg |
| 70 | 2 3/4 | 4x11 | 8x11 | 40° | 2 | - | 2.5 |
| 70 | 2 3/4 | 3x11, 1x9 | 6x11 | 35° | 3 | - | 2.5 |
| 70 | 2 3/4 | 4x10, 1x10 | 8x11 | 35° | 4 | - | 2.5 |
| 76 | 3 | 4x11 | 8x11 | 40° | 2 | - | 3.2 |
| 76 | 3 | 5x11 | 8x12 | 35° | 2 | 1 | 3.2 |
| 76 | 3 | 3x11, 1x11 | 6x13 | 35° | 3 | - | 3.2 |
| 76 | 3 | 4x11, 1x11 | 8x11 | 35° | 4 | - | 3.2 |
| 76 | 3 | 4x11, 1x11 | 8x12 | 35° | 4 | - | 3.2 |
| 89 | 3 1/2 | 4x13 | 8x13 | 40° | 2 | - | 5.4 |
| 89 | 3 1/2 | 6x11 | 8x12 | 35° | 2 | - | 5.4 |
| 89 | 3 1/2 | 3x11, 2x11 | 6x13 | 35° | 3 | 1 | 5.4 |
| 89 | 3 1/2 | 4x11, 1x11 | 8x12 | 35° | 4 | - | 5.4 |
| 89 | 3 1/2 | 4x13, 1x13 | 8x13 | 35° | 4 | - | 5.4 |
| 102 | 4 | 5x14 | 8x14 | 40° | 2 | - | 6.8 |
| 102 | 4 | 6x13 | 8x16 | 40° | 2 | 1 | 6.8 |
| 102 | 4 | 3x13, 2x13 | 6x14 | 35° | 3 | 1 | 6.8 |
| 102 | 4 | 4x13, 1x13 | 8x14 | 35° | 4 | - | 6.8 |
| 102 | 4 | 4x13, 2x13 | 8x13 | 35° | 4 | 1 | 6.8 |
Product Photos
Sollroc , with more 10 years of experience ,is one of the professional manufacturer and supplier of high performance rock drilling tools like: DTH hammers and bits, RC hammers and bits, DTH drill rods and top hammer drilling tools. Our tools are widely used in different drilling applications including mining, quarrying, water well drilling, geotechnical industries and etc.
