SD10 Shank 10'' Down The Hole DTH Hammer Carburized Steel For Construction
Product Introduce
The SOLLROC hammers maintain excellent operating pressure over an extended service life and overall is the tool you require to get the maximum out of all your equipment and guarantees that the quality you expect is always delivered.
Applications include oil & gas, construction, water well, and blast hole
Feature
All critical internal components are heat treated under strict control to maximize tool longevity
An overall cost-effective and user-friendly tool for use in the most demanding conditions
Working Principle
SOLLROC DTH hammer consist of only two moving parts: the piston and the valve. With so few moving parts, the smart solution delivers reliable high performance drilling in the most challenging conditions. Water, at up to 180 bar delivery pressure, is used to power the impact mechanism of the hammer at a high frequency rate. When the water leaves the hammer, it loses the pressure and keeps a low flush velocity. This however is still adequate to bring any cuttings to the surface and clean the borehole. Additionally, the hydrostatic column, which is created above the hammer, helps to keep the hole stable while preventing potential collapse. This also prevents water from being drawn into the borehole, which increases hole stability and prevents potential environmental issues.
Specification
| Shank | SD10 |
| Length (less bit) | 1525mm |
| Outer diameter | 226mm |
| Top sub thread | API 6 5/8" REG |
| Weight (less bit) | 316kg |
| Hole range | 254mm-311mm |
| Working pressure | 10-30bar |
| Impact rate at 1.7 Mpa | 20Hz |
| Recommended rotation speed | 15-25 r/min |
About us
We SOLLROC are a leading manufacturer of rock drilling tools, like DTH hammers and bits, DTH drill pipes, RC hammers and bits, tophammer button bits, coupling, cross bits, drill rods located in Changsha, Hunan, China.
We have rich experience in this field of DTH hammers and bits for over 20 years.
Owing to high quality, professional serivce and competitive price, we have gotton good reputation from our customers all over the world, such as France, Spain, Italy, South Africa, Australia, Iran, Malaysia, etc.
Delivery Time
Generally need 15-25 days
Transport Way
By air, By Sea or By Express
